Wheel Sand Washing Machine

Wheel Sand Washing Machine

For the machine sand, stone powder, mountain sand and other materials are deslimed, impurity removal, screening, to achieve the purpose of purification, in the process of washing less fine sand loss, high cleaning degree, more water saving

Performance Feature

• The structure of the wheel bucket sand washing machine is simple, the impeller transmission bearing device is isolated from the water and the water receiving material, which greatly avoids the phenomenon of bearing damage caused by water immersion, sand and pollutants, and greatly reduces the accident rate.

• The loss of fine sand and stone powder is very little, and the gradation and fineness modulus of washed construction sand meet the standard requirements.

• In addition to the screen almost no wearing parts, long service life, long-term without maintenance.

• Water resources can be recycled, and its cost input is better saved.

Working Principle

When the wheel sand washing machine is working, the motor drives the impeller to rotate slowly after decelerating through the triangle belt, reducer and gear. The sand and stone enter the washing tank with the feeding groove, roll under the drive of the impeller, and grind each other to remove the impurities covering the surface of the sand and stone, and destroy the water vapor layer covering the sand and stone, so as to facilitate dehydration; At the same time, add water to form a strong water flow, timely take away impurities and foreign bodies with small proportion, and discharge from the overflow outlet washing tank to complete the cleaning effect. Clean sand and stone are taken away by the blade and poured into the discharge tank from the rotating impeller to complete the cleaning of sand and stone.
